ELEGOO Centauri Carbon 3D Printer

50.201.020300
PA0111
MANUFACTURERELEGOO MPN50.201.020300
ELEGOO Centauri Carbon 3D Printer ELEGOO Centauri Carbon is an advanced 3D printer designed for professionals, engineers and 3D printing enthusiasts. Featuring state-of-the-art CoreXY heated bed kinematics and a robust construction, the device provides unparalleled precision, stability and...
41416
Χωρίς ΦΠΑ: 334.00
Μη Διαθέσιμο
Παράδοση
  • — ELTA Courier
  • — ACS Courier
  • — ΓΕΝΙΚΗ ΤΑΧΥΔΡΟΜΙΚΗ
Τρόποι πληρωμής

ELEGOO Centauri Carbon 3D Printer

ELEGOO Centauri Carbon is an advanced 3D printer designed for professionals, engineers and 3D printing enthusiasts. Featuring state-of-the-art CoreXY heated bed kinematics and a robust construction, the device provides unparalleled precision, stability and the ability to work with a wide range of materials. With a maximum nozzle temperature of 320°C and a built-in automatic leveling system, every print is precise and perfectly reproduced, regardless of the complexity of the model.

Stability at any speed

Centauri Carbon is distinguished by its robust cast aluminum frame and additional reinforcements in the form of four aluminum alloy pillars and stainless steel side panels. This design provides excellent stability even at high printing speeds. As a result, the machine can reach speeds of up to 500 mm/s, which significantly reduces production time without sacrificing quality.

Printing from demanding materials

The use of a closed chamber with an active heating system allows working with demanding filaments that require constant temperature conditions. Centauri Carbon supports a wide range of materials, including PLA, PETG, TPU, ABS, ASA, and carbon fiber-reinforced filaments, such as PETG-CF and PA-CF. This allows users to create both flexible and extremely durable models that withstand high temperatures and mechanical stress.

Cooling system - precision in every detail

Centauri Carbon is equipped with an advanced cooling system that includes a high-speed model fan, an auxiliary fan for the components, and an external housing fan. This solution guarantees optimal temperature in the chamber, which effectively prevents layer deformation and allows for extremely precise details in prints.

Stable filament feeding and automatic cutting

A hardened steel dual extruder ensures smooth and precise material feeding, even when printing at high speeds. The built-in automatic filament cutter allows for fast and precise material cutting and reversing, eliminating the problem of clogged nozzles and improving the overall reliability of the device.

CoreXY Kinematics - speed and accuracy

The use of CoreXY kinematics allows the printer to achieve high precision and printing speed, while reducing the weight of moving parts. As a result, the Centauri Carbon not only operates faster than standard 3D printers, but also provides better detail reproduction and higher print repeatability.

Automatic leveling and compensation of the Z axis

The printer is equipped with an automatic calibration system, which uses four precision pressure sensors and an intelligent Z-axis compensation algorithm. As a result, the user can fully focus on the design, and the table alignment itself is done with a single click, eliminating the need for manual adjustments.

Full control of printing

Centauri Carbon offers the printing process recording function with a built-in timelapse camera. Users can monitor the printing progress live, analyze any errors, and document the entire process in high resolution, which is particularly useful for industrial and educational applications.

A professional printer for the most demanding

The ELEGOO Centauri Carbon is a device that will meet the needs of both hobbyists and professionals. With a combination of high printing speed, precise temperature control, automatic leveling, and compatibility with a wide range of materials, this printer is an excellent choice for those looking for reliability and top-quality prints.

Included

  • Touch screen
  • Spool holder
  • Yarn sample
  • Power cable
  • Blockage removal tool
  • Allen key set (1.5/2.0/2.5/3.0 mm)
  • Screwdriver
  • Replacement windshield wiper nozzle/heating panel
  • USB
  • Scraper blade
  • User manual
ManufacturerELEGOO
Model50.201.020300



Body

Workspace256 x 256 x 256 mm
Working platform size260 x 260 mm
Product size398 x 404 x 490 mm
Gross weight21 kg



Speed

Printing speed≤ 500 mm/sec
Acceleration20000 mm/s2



Temperature

Ambient temperature5-40℃
Maximum heated bed temperature110℃
Maximum nozzle temperature320℃



Electrical requirements

Force1100 W at 220 V, 350 W at 110 V
Trend100-240V, 50/60Hz



Tool head

Nozzle1
Nozzle diameter0.4 mm (default)
Printing accuracy± 0.1mm
Layer thickness0.1-0.4 mm (0.2 mm recommended)
Extrusion typeTwo-speed extruder made of hardened steel
Reduction ratio5.2



Supported thread

RecommendedPLA, PETG, TPU, ABS, ASA, PLA-CF
CompatiblePETG-CF, ABS-CF, ASA-CF, PET-CF, PA-CF, PET, PC, PA
Thread diameter1.75mm
Thread cutterYes



Sensors

YesYarn leakage sensor
YesRecovering lost power
Yes



Cooling

High speed cooling fan modelClosed loop control
Auxiliary component cooling fanClosed loop control
Control panel fanClosed loop control
Chamber temperature controller fanClosed loop control
Air filterNano-mineral crystal filters



Electronics

ConnectivityUSB memory stick, Wi-Fi
Screen4.3 inch color capacitive touch screen
MotherboardDual-core, fast and quiet motherboard



Software

Shredding softwareELEGOO Slicer (recommended)
Supported file formatsSTL, OBJ, 3MF, STP
File format for printingGcode

MANUFACTURER
ELEGOO
MPN
50.201.020300
EAN
6932704905128
