IMOU LAN Switch 8 ports 100Mb/s IMOU SF108C (Black)

LAN Switch 8 ports 100 Mb/s IMOU SF108C

The IMOU SF108C LAN Switch provides fast and stable network connectivity with 8 RJ45 ports. It offers automatic speed configuration in the 10/100Mbps range and the Auto MDI/MDIX function eliminates the need for crossover cables. In addition, the 802.3X Flow Control protocol ensures effective data flow control. Finally, the device is easy to install, while the Plug & Play function enhances user convenience.

Direct connection

The SF108C model provides high performance and connectivity flexibility. It is equipped with 8 RJ45 ports, making it ideal for handling large data traffic and ensuring the performance required by modern network applications. All ports support auto-negotiation, allowing automatic adjustment of data transmission speed from 10 to 100Mbps. As a result, the switch is widely compatible with various devices and allows optimizing the connection speed based on current needs, ensuring smooth and efficient network operation, whether you are sending large files, streaming high-definition video, or using advanced applications.

Efficient data flow management

The device supports the advanced 802.3X Flow Control function, ensuring stability and efficiency of data flow within the network. The implemented flow control mechanism allows for the management and coordination of data transmission between the switch and connected devices, which is necessary during high network load. As a result, the switch effectively prevents data packet loss and reduces the risk of network congestion, which makes it an excellent solution for both advanced home applications and demanding professional uses.

Efficient operation

The switch is unmanaged, which translates into user-friendly operation without the need for complex settings. It offers an overall throughput of 1.6Gbps and a packet forwarding rate of 0.1488Mpps per port. The packet buffer memory is 768Kb, allowing for efficient handling of network traffic. The device also supports Jumbo frames up to 2K and has a 2K MAC address table. It also provides surge protection up to 2KV in common mode and 1KV in differential mode.

Easy configuration

Support for Auto MDI/MDIX makes the IMOU switch automatically detect the type of cable connected, eliminating the need for special crossover cables, thereby simplifying the network configuration process. Another advantage is Plug & Play, a feature that ensures immediate operation of the device without the need to install additional drivers.

Thoughtful design

The device's housing is made of high-quality plastic, offering both low weight (86g) and durability. The switch's dimensions are just 133.2 x 62 x 21mm, allowing for easy wall or desk mounting.
