Avatto WSM16-DC-1 1-channel WiFi smart switch module with voltage-free DC contact
The Avatto WSM16-DC-1 Smart 1-Channel WiFi Switch Module with DC Voltage-Free Contact allows you to easily automate the control of lighting, home appliances or low-voltage systems. With Wi-Fi connectivity, you can turn connected devices on and off from anywhere in the world using the Smart Life or AVATTO apps. The module works with Amazon Alexa and Google Assistant, allowing for hands-free control with voice commands.
Easy installation and wide compatibility
The compact housing (39 × 39 × 19.4 mm) makes it easy to install in an installation box, distribution box or directly on the device. The Avatto WSM16-DC-1 operates in the AC voltage range of 100-240 V 50/60 Hz and supports a maximum load of 5 A / 150 W for LED lighting. The unit will work well in both low and high voltage installations, as well as in configurations with one or two switches. Thanks to its wide compatibility and simple wiring diagram, the device is friendly to both professional installers and individual users.
Safe and reliable operation
The Avatto WSM16-DC-1 features a manual override function, allowing you to turn a circuit on and off even if the Wi-Fi connection is lost. The device remembers the last settings in memory and automatically reproduces them when the power supply is restored. The robust construction, CE and RoHS certifications and IP20 protection ensure safe use in home and office environments.
Automation and collaboration with the smart home ecosystem
The Smart Life / AVATTO application allows not only remote control, but also scheduling, creating automatic scenes and sharing control with other household members. The unit operates on a 2.4 GHz Wi-Fi network in the IEEE 802.11 b/g/n standard, which guarantees a stable connection and fast response time. With its help, it is easy to integrate lighting and appliances into an existing smart home system, increasing the comfort and efficiency of everyday use.
Included
- Avatto WSM16-DC-1 1-channel WiFi smart switch module with voltage-free DC contact
- Support base
- User manual
Specifications:
| Manufacturer | Avatto |
|---|
| Model | WSM16-DC-1 |
|---|
| Device type | 1-channel WiFi switch module (DC contact without voltage) |
|---|
| Supply voltage | AC 100-240V, 50/60Hz |
|---|
| Maximum load | LED 150W / 5A |
|---|
| Transmission frequency | 2.412-2.484 GHz |
|---|
| Communication protocol | Wi-Fi IEEE 802.11 b/g/n |
|---|
| Operating range | < 100m |
|---|
| Dimensions | 39 × 39 × 19.4mm |
|---|
| Degree of protection | IP20 |
|---|
| Operating time | >100,000 cycles |
|---|
| Certifications | CE, RoHS |
|---|
