The GL-C-201P Gledopto Pro is a new member of the professional LED control family with Zigbee 3.0 + RF receiver.It can operate in 5 different modes: RGBCCT, RGBW, RGB, CCT (WW/CW) and Dimmer, and can control 12V – 24V DC LEDs with functions according to the type of LED (colour adjustment, colour temperature adjustment for white light, brightness control), making it compatible with almost all LED lighting.
It is compatible with eWeLink (Sonoff and SmartWise) Zigbee Bridge, Tuya / SmartLife Zigbee gateways, Philips Hue bridge, some Amazon Zigbee bridges, Aeotec SmartThings hub, and Terncy (Apple Homekit compatible) Zigbee gateway, and a range of other systems.
Not only can it be automated and remotely controlled via Zigbee from an app, but it can also be remotely controlled via Gledopto’s 2.4GHz RF remote control and wireless RF wall panel, and has an input for push-button switches, so it can be controlled from wall switches (on/off and dimming).
Additional information
| General |
|---|
| Brand | Gledopto |
|---|
| Factory SKU ID | GL-C-201P |
|---|
|
| Electricity properties |
|---|
| 2-way or 3-way switching | it can be controlled from multiple Gledopto RF 2.4GHz remote controllers and wireless wall panels |
|---|
|
| Smart home protocols |
|---|
|
| Remote control, smart control |
|---|
| Cloud mode | depends on the Zigbee Bridge |
|---|
|
| More features |
|---|
| Direct local remote control | yes, wireless local remote control supported from Gledopto 2.4GHz remote controllers and wall panels |
|---|
| Operating temperature range | -20℃ – 45℃ |
|---|
| Dimmer feature | yes |
|---|
| DIN rail compatible | no |
|---|
| External switch supported | yes |
|---|
| IP rating | IP20 |
|---|
| LAN mode | depends on the Zigbee Bridge |
|---|
| MQTT support | depends on the Zigbee Bridge |
|---|
| Notification functions | depends on the Zigbee Bridge |
|---|
| Power consumption metering | no |
|---|
| Rated current (output) | 20A (including all channels) |
|---|
| RF transmitter / receiver | 2.4GHz RF receiver |
|---|
| Schedulers, timers | depends on the Zigbee Bridge |
|---|
| Thread | no |
|---|
| Web admin interface | depends on the Zigbee Bridge |
|---|
| Wi-Fi | no |
|---|
| Zigbee | yes |
|---|
| Z-Wave | no |
|---|
| Physical on/off button on device | no |
|---|
| Device power supply | 12V DC / 24V DC |
|---|
| Bundle | No |
|---|
| Size | 125 x 37 x 24 mm |
|---|
| Supported protocols | RF receiver (2.4 GHz), Zigbee |
|---|
| Warranty type | Warranty |
|---|
| Type of the product | LED / RGB(W) controller |
|---|
| History / Event log | depends on the Zigbee Bridge |
|---|
| Output circuits / gangs | 5 (RGBCW channels) |
|---|
| Power supply | DC (below 60V) |
|---|
| Smartphone app | eWeLink, Tuya/SmartLife, SmartThings, Hue, depending on Zigbee bridge |
|---|
| Dimensions | 12,5 × 3,7 × 2,4 cm |
|---|
|
