Shelly PRO 3EM 120A electricity meter with 3 functions: WiFi/Bluetooth/Matter

Κωδικός Κατασκευαστή (MPN): PRO 3EM Matter

ΚΩΔΙΚΟΣ: EA1164

MANUFACTURERSHELLY MPNPRO 3EM Matter

Shelly PRO 3EM 120A three-phase electricity meter with WiFi/Bluetooth/Matter Shelly Pro 3EM 120A is a professional, three-phase electricity meter designed for DIN rail mounting. The device records accumulated energy with an accuracy of 1%, as well as instantaneous voltage, current and power...

€155⁵⁶

Χωρίς ΦΠΑ: €125.45

Σε Απόθεμα

+ −

Παράδοση

— ELTA Courier
— ACS Courier
— ΓΕΝΙΚΗ ΤΑΧΥΔΡΟΜΙΚΗ

Τρόποι πληρωμής

Περιγραφή
Χαρακτηριστικά
Skroutz Αξιολογήσεις

Shelly PRO 3EM 120A three-phase electricity meter with WiFi/Bluetooth/Matter

Shelly Pro 3EM 120A is a professional, three-phase electricity meter designed for DIN rail mounting. The device records accumulated energy with an accuracy of 1%, as well as instantaneous voltage, current and power for each phase in real time. It stores data from the last 60 days at one-minute intervals for each phase, allowing for detailed analysis. It can operate autonomously on a local LAN and/or Wi-Fi network, or be managed via a home automation cloud service using MQTT, HTTP and WebSocket protocols. In addition, thanks to the scenario creation feature, it allows the creation of advanced scenarios and offers extensive monitoring options. The device is also compatible with the Matter standard, making it even easier to integrate it into selected smart home systems.

Electrical panel components, including the Shelly Pro smart relay, circuit breakers and wiring.

Specifications:

Manufacturer	Shelly
Model	PRO 3EM Matter
AC power supply	100 - 260V, 50/60Hz
Power consumption	< 3W
Internal temperature sensor	Yes
Voltmeters (RMS for each phase)	100 - 260V
Voltmeter accuracy	±1>#/td###
Ammeters (RMS via current transformers for each phase and neutral)	0 - 120A
Compatible current transformer (CT)	CT 120A
Ammeter accuracy	±1% (2 - 120 A), ±2% (1 - 2 A), ±5% (0 - 1 A)
Active and apparent energy and power meters	Active and apparent power, active and apparent energy, power factor, active energy and basic reactive energy
Calibration between channels at minimum load	500 W per channel
No-load limit	30 VA per channel
Measurement data storage:	At least 60 days with 1 minute data analysis
Wi-Fi protocol	802.11 b/g/n
Wi-Fi range	Up to 30 m indoors and 50 m outdoors
Bluetooth protocol	4.2
Bluetooth range	Up to 10 m indoors and 30 m outdoors
CPU	ESP32-D0WDQ6
Flash memory	16MB
Dimensions	94 x 19 x 69 ±0.5mm
Weight	62 ±1g
Support	DIN rail
Housing material	Plastic
Ambient temperature	-20°C to +40°C
Moisture	30% to 70% RH
Maximum altitude	2000 m
Compatibility with Matter	Yes
