SONOFF MINI-ZB2GS-E Dual Channel ZigBee Wall Switch.

SONOFF MINI-ZB2GS-E Two-channel ZigBee Wall Switch

SONOFF MINI-ZB2GS-E is a state-of-the-art two-channel ZigBee 3.0 wall switch, designed for stable, fast and secure control of lighting and other electrical circuits. It allows independent control of two loads, acts as a ZigBee router to strengthen a mesh network, offers Detach Relay function, support for scenes, schedules, voice control and integration with popular smart home platforms - all in a sleek, minimalist flush-mount form factor.

Stable ZigBee 3.0 communication and dual channel support

The switch uses the ZigBee 3.0 protocol (IEEE 802.15.4), ensuring low latency and high reliability of operation. It is important that the device acts as a ZigBee router, thereby strengthening and extending the range of the mesh network in the home. The ceramic antenna used and the Enhanced / Turbo Mode function further improve the stability of the connection, which translates into more reliable operation of the entire smart home system - especially in larger apartments and houses. In addition, the dual-channel design allows you to control two circuits from one point, such as a ceiling lamp and a table lamp or two lighting zones in one room. Such a solution means fewer switches on the wall, a consistent look and greater convenience on a daily basis - both for manual control and from the application. Each channel can be configured independently - including automation and scenes.

Detach Relay function - ideal for smart bulbs

The detach relay function ensures that the physical button does not interrupt the power supply, but only sends a control command. As a result, smart bulbs do not lose their connection to the network and are not switched off after using a wall switch. In addition, it is possible to use ZigBee Binding, i.e. directly connecting a button to another ZigBee device - without the participation of the cloud, which ensures an immediate response even if the Internet is temporarily absent.

Scenes, schedules and automations

MINI-ZB2GS-E allows you to create smart scenes - such as automatically turning on the lights when motion is detected or delaying the activation during power supply. The user can determine the behavior of the device when the power supply is restored (activation mode), including setting a delay for turning on the light, which prevents its accidental activation after a power outage. Schedules and timers allow you to adjust the operation of the lighting to the rhythm of the day of household members, increasing comfort and a sense of security.

Wide compatibility with smart home platforms

The device works with the eWeLink app and Home Assistant (ZHA and Zigbee2MQTT), offering extensive configuration options for more advanced users. It can be used with various ZigBee hosts, including ZBBridge-P, ZBBridge-U, NSPanel Pro, iHost and ZigBee Dongles (ZBDongle-P/E, Dongle Plus MG24, Dongle Lite MG21). It also supports voice control via Amazon Alexa and Google Home. Integration with Apple Home is only possible via Matter Bridge - requires a compatible Matter gateway and a suitable environment (e.g. eWeLink CUBE).

Safety, durability and easy operation

The fireproof PC plastic housing, overvoltage and overheating protection and the long-life relay (up to 100,000 cycles) make the switch suitable for heavy daily use. CE and RoHS certifications confirm the high quality of construction. The switch fits into standard type 86 mounting boxes and European round boxes (Ø60 mm). Configuration is done in a few steps in the eWeLink application - a compatible ZigBee hub is required for operation, which allows the device to communicate with the smart home system. SONOFF MINI-ZB2GS-E also supports remote OTA software updates, allowing you to develop its functions without disassembly.

Included: The device includes: 1:

• SONOFF MINI-ZB2GS-E two-channel ZigBee wall switch
• Mounting screws
• User manual
